Engine Parameters

Manufacturer

CSSC

Type

QY16V132

No.of cylinders

16

Type of cylinders

V

Angle of cylinders

60°

Operation mode

Four stroke spark plug ignition

Displacement

L

35.03

Bore /Stroke

mm

132/160

R P M

RPM

1500

Compression ratio

14

Average piston speed

m/s

Average effective pressure

bar

16

Lubricating oil tank volume -min/max

L

98

Oil consumption

g/kWh

<0.1

Maximum allowable exhaust

back pressure

mbar

50

Technical Parameters

100%

75%

50%

Output power

kW

700

525

350

Thermal output

kW

864

676

493

Cooling water heat

kW

280

246

211

Primary air cooling heat

kW

88.5

40.5

-

Secondary air cooling heat

kW

62.8

41.9

26.6

Exhaust gas heat

kW

432.3

347.6

255.9

Energy input

kW

1,700.0

1,300.0

910.0

Efficiencies electrical

%

41.2%

40.4%

38.5%

Efficiencies thermal

%

50.8%

52.0%

54.2%

Efficiencies total

%

92.0%

92.4%

92.7%
